Barometric Pressure (BARO)

Sensor Data

The BARO sensor contains a pressure sensing element, a capacitor, and signal conditioning electronics. The capacitor has a pressure reference  which results in one surface if the capacitor being partially deflected. Further changes in atmospheric pressure deflects the surface further and produces a change in capacitance , which is converted to a frequency by the conditioning electronics.
